    To the Development and Manufacture

    New Energy Vehicle

    Metrology Solutions for New Energy Vehicles

    The automotive industry is rapidly accelerating development and release of new energy vehicles (NEVs). Since the  construction of electric powertrains differs significantly from those of combustion engine vehicles, car manufacturers and suppliers need to reinvent themselves to adapt the production and assembly of critical electric vehicle components.

    Key Components found in New Energy Vehicle that can be measured
    by Mitutoyo Measuring Equipments

    POWER CONTROL UNIT (PCU)
    media

    Insulated Gate Bipolar Transistor (IGBT)

    Transistor daya dari inti inverter. Aliran utama dari IGBT adalah perakitan komponen semikonduktor. Alat ukur Microscope MF-U Mitutoyo cdapat digunakan untuk observasi yang efektif dan mengkonfirmasi retakan pada solder yang terhubung ke chip dengan memberikan pengamatan resolusi tinggi dan solusi pengukuran dengan akurasi tinggi.



    Produk pengukuran yang diunggulkan:

    Measuring Microscope – MF/MF-U+ Vision Unit

    ① Kondisi dari Soldering Iron

    FUEL CELLS
    media

    Hydrogen-Oxygen Fuel Cell Separator

    Untuk membentuk jalur aliran untuk menyebarkan gas, pemisah sel bahan bakar diproses didalam bentuk concave-convex yang kecil. Menggunakan sistem pengukuran micro-form UMAP dengan ultra-low force 15  µm dan minimum 1 µN, Pengukuran dengan keandalan tinggi dicapai dalam hal sudut R, jarak, sudut dll.



    Produk pengukuran yang diunggulkan:

    Vision Measuring Machine with Micro-Form Scanning Probe – UMAP Vision

    ① Jarak ② Radius ③ Lereng

    CHARGER AND CHARGING PORT
    media

    Pengisi Daya Mobil

    Pengisi daya mobil terdiri dari variasi part seperti cover, connector, housing dan relay. Seri Mitutoyo CRYSTA-APEX V menawarkan fleksibilitas dengan berbagai model yang sesuai dengan hampir semua ukuran benda kerja.



    Featured Measuring Product:

    CNC Coordinate Measuring Machine – CRYSTA-Apex V

    ① Dimensi (Lubang Diameter, Tebal, Tinggi, Posisi)
    ② Profile dari permukaan
