ABSOLUTEDigimaticIndicatorID-N/BSERIES543̶withDust/WaterProtectionConformingtoIP66•Slimbodydesign(bodywidth:only35mm).•RatedtoIP66:canbeusedsatisfactorilyeveninadverseenvironments.•TheABS(absolute)scalerestoresthelastoriginposition*automaticallywhentheindicatoristurnedon,andrealizeshighreliabilitybyeliminatingover-speederrors.•Backplungerdesign(ID-B)iswidelyusedfordialindicators.A5mm-strokeplungerwithahigherdegreeofaccuracyhasbeenimplementedbyadoptingadirectreadingscaleforplungerdisplacement.•Tolerancejudgmentcanbeperformedbysettingupperandlowertolerancelimits.•Equippedwithadataoutputportthatenablesincorporationintomeasurementnetworkingandstatisticalprocesscontrolsystems.*Referto“OriginSettingofDigimaticIndicators”onpage2-33.543-575543-585RatedtoIP66water-anddust-proofingstandardandoilresistanceimproved.Bodywidth35mmTipsFordetailsofeachmark,seeIntropage13.LCDreadoutreversalfunctionIP66dust/waterprotectionlevelLevel6:Dust-proofNoingressofdustallowed.Level6:ProtectedagainstpowerfulwaterjetsWaterprojectedinpowerfuljetsagainsttheenclosurefromanydirectionshallhavenoharmfuleffects.Fordetailsonthedust/waterprotectionleveltestconditions,refertoIEC60529:2013andJISC0920:2003.Referto"Optionalaccessories"onpage2-30.2-7
| <
|
> |
>>
